Self-service kiosk gallery
Engineered for high-volume QSR and retail environments. Our kiosks feature industrial-grade Rockchip motherboards, seamless payment terminal integration, and rugged anti-vandal enclosures designed for 24/7 continuous operation.
| Motherboard | Rockchip RK3568 (Quad-core Cortex-A55) or Raspberry Pi 5 |
|---|---|
| RAM / Storage | 4GB LPDDR4 / 32GB eMMC (Upgradable) |
| OS Environment | Android 11/12 (Rooted) or Linux Debian |
| Network | Gigabit Ethernet, Dual-band Wi-Fi 6, Optional 4G/5G module |
| I/O Interfaces | 4x USB 3.0, 2x RS232, 1x HDMI Out, Audio Out |
| Panel Type | Industrial IPS LCD (LG/BOE original A-grade) |
|---|---|
| Resolution | 1920 x 1080 (FHD) / 3840 x 2160 (4K optional) |
| Brightness | 350 nits (Standard indoor) up to 1000 nits |
| Touch Tech | 10-point PCAP (Projected Capacitive) |
| Glass Protection | 3mm Tempered Anti-Glare, Mohs 7H hardness |
| MOQ | 1 unit (sample) / 10 units (OEM production) |
|---|---|
| Lead time | 15–20 days |
| Certifications | CE, FCC, RoHS |
| Warranty | 12-month manufacturer's warranty |
| Shipping terms | DDP/DDU worldwide |
| Country of origin | China (Hangzhou factory) |
| Import documents | CE Declaration of Conformity, RoHS and FCC documentation with every shipment |
| Models | IS-AD65F / IS-AD75F / IS-AD85F |
|---|---|
| Resolution | 4K UHD (3840 x 2160), 16:9 Ratio |
| Brightness | 270 - 320 cd/m² |
| Contrast Ratio | 1400:1 |
| Touch Tech | No Touch (Interactive options available) |
| OS & Core | Lango V100 Android 12 |
|---|---|
| RAM / ROM | 2 GB RAM / 32 GB ROM |
| Color / Build | Black Enclosure (Standing Floor Type) |
| Audio | Built-in 2x 5W (8Ω) Speakers |
| Customization | Windows OS / Higher Android Versions Optional |
| Screen sizes | 10″ – 86″ |
|---|---|
| Resolution | 1920 × 1080 (FHD) |
| Brightness | ≥300 cd/m² |
| Contrast ratio | 3000:1 |
| OS | Android |
| Touch | Multi-point capacitive |
|---|---|
| Camera | Built-in (facial recognition ready) |
| Location | GPS module optional |
| Card reader | IC / magnetic swipe / NFC |
| Printer | 80 mm thermal receipt printer |
Custom CNC bracket designs to perfectly fit your chosen payment terminals (Ingenico Lane/3000, Verifone, Pax). Pre-integrated 80mm Seiko thermal printers and 2D barcode scanners.
1.5mm cold-rolled steel with automotive-grade powder coating. We provide full 3D CAD modeling for custom shapes, colors (RAL matching), and illuminated acrylic logos.
Firmware-level customization including custom boot logos, pre-installed client APKs, kiosk-mode lockdown (MDM ready), and UI localization.
The Rockchip RK3568 motherboard is the standard choice for high-volume deployments: it ships with a locked-down Android build, MDM-ready kiosk mode, and a production run we can guarantee identical across repeat OEM orders. Raspberry Pi 5 is available for buyers who want a Linux/Debian stack, a smaller batch run, or in-house firmware control — it suits pilots and technical integrators who plan to write their own kiosk software rather than use our Android build. Both boards drive the same 10-point PCAP touch panel and Ingenico Lane/3000, Verifone, or Pax payment-terminal integration, so the board choice affects your software stack and lead time, not the payment hardware itself.
Countertop kiosks (21.5"–43") suit checkout lanes, reception desks, and self-order stations where floor space is limited and the unit sits on an existing surface — most QSR and retail OEM orders fall in this range. Standing-floor kiosks (65", 75", 85") are built for lobbies, transit stations, and self-service information points where the display needs to be visible from across a room; these use the 4K UHD panel and black steel enclosure rather than the countertop's compact chassis. Buyers unsure which fits their install should start with the countertop range — it's the lower-MOQ, faster-lead-time option for testing a rollout before committing to floor units.
Sample orders start at 1 unit; OEM production runs at 10 units minimum, with 15–20 day lead time from deposit for standard configurations (longer for custom enclosure colors or CNC-milled payment-terminal brackets). Every kiosk ships CE, FCC, and RoHS certified, with full compliance documentation for EU and North American import. Confirm your payment-terminal model at quote stage — we pre-fit CNC brackets for Ingenico, Verifone, and Pax hardware; custom brackets for other terminals add 5–7 days to the lead time.
For a real deployment that covers this same payment-terminal and enclosure work end to end, see our case study: 10 self-service ordering kiosks shipped to a Polish restaurant operator, with Ingenico Lane 3000 integration and DDP delivery.
Last updated: 31 August 2026
SkyTroni Screens accepts a 1-unit sample order before committing to production. OEM production runs start at 10 units, with a standard 15–20 day lead time from deposit for standard configurations.
Kiosks ship with CNC-milled brackets pre-fitted for Ingenico Lane/3000, Verifone, and Pax payment terminals, plus an integrated 80mm Seiko thermal printer and 2D barcode scanner. Custom brackets for other terminal models add 5–7 days to the lead time.
Yes. Enclosure color, CNC bracket design, firmware boot logo, and kiosk-mode lockdown are customized per order and confirmed at quote stage. Every unit ships CE, FCC, and RoHS certified with compliance documentation for EU and North American import.
The Rockchip RK3568 ships with a locked-down Android build and MDM-ready kiosk mode built for identical repeat OEM production runs. Raspberry Pi 5 suits smaller pilot batches and buyers who want a Linux/Debian stack and in-house firmware control. Both drive the same 10-point PCAP touch panel and payment-terminal integration. For the same comparison applied to our interactive flat panel range, see RK3588 vs RK3568: which processor is better for your interactive flat panel?
There is no single answer, and any supplier who gives you one without asking about the build is guessing. Customs classifies a kiosk on what it actually does — a unit built around a payment terminal, a touchscreen information point and an ADP-based kiosk fall in different headings. SkyTroni Screens sends the build sheet so your broker can classify it; country of origin is China.
